STAINLESS STEEL 304 FLANGES

//STAINLESS STEEL 304 FLANGES
STAINLESS STEEL 304 FLANGES 2017-10-13T04:58:54+00:00

MANUFACTURER OF STAINLESS STEEL 304 FLANGES | ASTM 182 STAINLESS STEEL 304 FLANGES | ASTM 240 STAINLESS STEEL 304 FLANGES | ANSI/ASME B16.1 STAINLESS STEEL 304 FLANGES

STAINLESS STEEL 304 FLANGES Exporter | STAINLESS STEEL 304 FLANGES Supplier | STAINLESS STEEL 304 FLANGES Manufacturer

UNIFLEX INDIA are one of the principle producers and exporters of unrivalled quality STAINLESS STEEL 304 FLANGES, These STAINLESS STEEL 304 FLANGES in run of the typical particulars, which finds applications in high requesting for business undertakings and divisions, particularly high temperature and acidic organizations. Our STAINLESS STEEL 304 FLANGES are strong, tough and at standard with overall quality and wellbeing models. We are powerful in offering our reputed clients with biggest quality STAINLESS STEEL 304 FLANGES . Our offered STAINLESS STEEL 304 FLANGES are produced using high survey tough steel as the crude material to ensure tip top and whole deal usage. Further, these 304 FLANGESare comprehensively used as machined parts, pump shafts, valves, clasp and handles.

We exports  Stainless Steel 304 Forged Flanges, Stainless Steel 304 Blind Flanges, Stainless Steel 304 Reducing Flanges, Stainless Steel 304 Orifice Flanges, Stainless Steel 304 Socket Weld Flanges, Stainless Steel 304 Slip On Flanges, Stainless Steel 304 Flat Flanges, Stainless Steel 304 Lapped Joint Flanges, Stainless Steel 304 SWRF Flanges, Stainless Steel 304 Square Flanges, Stainless Steel 304 Threaded Flanges, Stainless Steel 304 Weld Neck Flanges Series A or B, Stainless Steel 304 WNRF Flanges, Stainless Steel 304 Expander Flanges, Stainless Steel 304 High Hub Blinds Flanges, Stainless Steel 304 Spectacle Blinds Flanges, Stainless Steel 304 Loose Flanges, Stainless Steel 304 RTJ Flanges, Stainless Steel 304 Screwed Flanges, Stainless Steel 304 Weld Neck Flanges, Stainless Steel 304 Flange Facing Type & Finish, Stainless Steel 304 SORF Flanges, Stainless Steel 304 Groove & Tongue Flanges, Stainless Steel 304 Long Neck Weld Flanges, Stainless Steel 304 Spades Ring Spacers Flanges, Stainless Steel 304 Ring Type Joint Flanges, Stainless Steel 304 Weldo / Nipo Flanges.

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
304 S30400 304S31 58E 1.4301 X5CrNi18-10 2332 SUS 304
These comparisons are approximate only. The list is intended as a comparison of functionally similar materials not as a schedule of contractual equivalents. If exact equivalents are needed original specifications must be consulted.
Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
304 515 205 40 92 201
304H also has a requirement for a grain size of ASTM No 7 or coarser.
Designation A 182 / A 240, SA 182 / SA 240
Class 150#, 300#, 400#, 625#, 900#, 1500# & 2500#
Size 1/2″ NB TO 48″ NB
Standards ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings, ASTM, ASME Flanges, ANSI Flanges, DIN Flanges, EN Flanges, BS Flanges etc.
Grade A 182 304
Grade 304 C Mn Si P S Cr Mo Ni N
min. 18.0 8.0
max. 0.08 2.0 0.75 0.045 0.030 20.0 10.5 0.10
Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (m/m/0C) Thermal Conductivity (W/m.K) Specific Heat 0-1000C (J/kg.K) Electrical Resistivity (n.m)
0-1000C 0-3150C 0-5380C at 1000C at 5000C
8000 193 17.2 17.8 18.4 16.2 21.5 500 720
