Lap Joint Flanges ASME B16.5 Manufacturers, Exporters & Suppliers in India.</21>

304/304L Lap Joint Flanges (SOLJ), 310/310S Lap Joint Flanges (SOLJ), 316/316L Lap Joint Flanges (SOLJ), 317/317L Lap Joint Flanges (SOLJ), 321/321H Lap Joint Flanges (SOLJ), 347/347H Lap Joint Flanges, 446 Lap Joint Flanges.

Stainless Steel, Alloy Steel, Carbon Steel, Duplex steel, Copper Nickel Alloy, Hastelloy, Titanium, Alloy 20, Monel & Inconel Lap Joint Flanges.


This is again similar to a slip-on flange, but it has a radius at the intersection of the bore and the flange face toaccommodate a lap stub end. The face on the stub end forms the gasket face on the flange. This type of flange is used in applications where section of piping systems need to be dismantle quickly and easily for inspection or replacement.



Material of Construction Standard Grades
Stainless Steel Lap Joint Flanges ASTM A182 , A240 F 304, 304L, 304H, 316, 316Ti, 316H, 316L, 316LN, 309S, 309H, 310S, 310H,317, 317L, 321, 321H, 347, 347H, 201, 202, 904L
Carbon Steel Lap Joint Flanges ASTM A105 Gr. F42,46,52,56,60,65,70
Alloy Steel
Lap Joint Flanges
ASTM A182 F1,F5,F9,F11,F22,F91
Nickel Alloy
Lap Joint Flanges
ASTM SB564, SB160, SB472, SB162 Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020),
Copper Alloys Lap Joint Flanges ASTM SB 61 , SB62 , SB151 , SB152 UNS No. C 70600 (Cu-Ni 90/10), C 71500 (Cu-Ni 70/30), UNS No. C 10100, 10200, 10300, 10800, 12000, 12200,
Low Temperature Carbon Steel Lap Joint Flanges ASTM A350 LF2 , LF3
Duplex Steel Lap Joint Flanges ASTM A182, A240 UNS F 44, F 45, F51, F 53, F 55, F 60, F 61



Dimensional Tolerances of Lap Joint Flanges ASME B16.5



Outside Diameter
≤ 24 = 1.6 mm | > 24 = ± 3.2 mm
Inside Diameter
≤ 10 = ± 0.8 mm | ≥ 12 = + 1.6 mm / – 0 mm
Diameter of Contact Face
1.6 mm Raised Face = ± 0.8 mm
6.35 mm Raised Face, Tongue & Groove / Male-Female = ± 0.4 mm
Outside Diameter of Hub
≤ 12 = + 2.4 mm / – 1.6 mm | ≥ 14 = ± 3.2 mm
Diameter of Counterbore
Same as for Inside Diameter
Drilling
Bolt Circle = 1.6 mm | Bolt Hole Spacing = ± 0.8 mm
Eccentricity of Bolt Circle with Respect to Facing
≤ 2½ = 0.8 mm max. | ≥ 3 = 1.6 mm max.
Thickness
≤ 18 = + 3.2 mm / – 0 | ≥ 20 = + 4.8 mm / – 0
Length thru Hub
≤ 18 = + 3.2 mm / – 0.8 mm | ≥ 20 = + 4.8 mm / – 1.6 mm
